Hilltip SprayStriker™ Hi-Flow de-icing sprayers

SprayStriker™ 500-2650 Hi-Flow de-icing sprayer for trucks

HI-FLOW DE-ICING SPRAYERS

Our NEW SprayStriker™ HFE-series sprayers are the largest sprayers in the SprayStriker™ product family. These truck bed mounted de-icing sprayers have liquid tank capacities of 500-2650 gallons. Our fully 12V/24V electric-powered de-icing sprayers help contractors reduce salt usage while increasing their level of service.

SprayStriker™ HFE-series sprayers come standard with StrikeSmart™ controllers with GPS speed control and HTrack™ 2-way GPRS tracking and control system.

LIQUID SPRAYER DESIGN

The sprayer is designed for maximum liquid tank capacity and for use on different lengths of truck beds and municipal trucks. The durable and light poly tanks are supported by a powder coated stainless-steel frame construction. The dual
Hi-Flow pumps, motors, valves and CPU-units are protected inside an easy-to-reach stainless steel cabinet.

Brine sprayer, Liquid de-icing equipment, De-icing sprayer, Liquid de-icing sprayers, Salt brine sprayer

HTRACK™ TRACKING SYSTEM

This truck brine sprayer is compatible with our standard HTrack™ tracking software. You can track and manage all of your spreading devices and snowplows online on your computer, tablet or smartphone. The program shows treatment route and spreading details on the map in real-time or between specific time intervals. Spreading route details such as speed, GPS location and material used can be summarized and generated as PDF reports.

Read more

When using salt brine solution as
de-icing method, you save up to 75% on your salt used on each route, and reduce the impact on the environment!

FUNCTIONS AND ACCESSORIES


Brine sprayer, Liquid de-icing equipment, De-icing sprayer, Liquid de-icing sprayers, Salt brine sprayer

COLOR SCREEN CONTROLLER

The controller lets you customize your spreading session according to your current situation. Automatic GPS-speedcontrol adjusts the amount of spreading material (gal/1000 sq ft) according to your vehicle speed, while manual mode lets you insert a fixed auger speed. The controller additionally collects and saves essential data to an USB memory, allowing you to generate spreading reports. The controller also makes it easy to turn on functions, like vibrator, beacon and work light, from inside the cabin.

Brine sprayer, Liquid de-icing equipment, De-icing sprayer, Liquid de-icing sprayers, Salt brine sprayer

SPRAY BAR

2-lane, 90” wide spray bar with double spray and side nozzles

Brine sprayer, Liquid de-icing equipment, De-icing sprayer, Liquid de-icing sprayers, Salt brine sprayer

BEACON WARNING LIGHT

IP 67 rated Beacon warning light

12V dual Hi-Flow pumps with spray bar output of 30 gal/min

HI-FLOW PUMPS

12V dual Hi-Flow pumps with spray bar output of 20 gal/min

Brine sprayer, Liquid de-icing equipment, De-icing sprayer, Liquid de-icing sprayers, Salt brine sprayer

SPEED CONTROL

StrikeSmart™ controllers with GPS speed control and HTrack™ 2-way GPRS tracking and control system

ALSO INCLUDED

  • Self-loading and pump out feature with 2” camlock connection
  • LED work light (white)
Brine sprayer, Liquid de-icing equipment, De-icing sprayer, Liquid de-icing sprayers, Salt brine sprayer

MANUAL DE-ICING HOSE REEL

65’ stainless steel hose reel for de-icing hard to reach areas

Brine sprayer, Liquid de-icing equipment, De-icing sprayer, Liquid de-icing sprayers, Salt brine sprayer

24V MOTORS & BATTERY POWER KIT

24V motors and battery power kit (2 x 115Ah)

Brine sprayer, Liquid de-icing equipment, De-icing sprayer, Liquid de-icing sprayers, Salt brine sprayer

LEG STAND

Storage leg stand

OTHER OPTIONAL FEATURES

  • 3-lane, 100” wide spray bar with double spray and side nozzles
  • Self loading leg stand for dump bodies
Spreader Anti-Icing

ANTI-ICING

By applying a liquid solution before the snow or rain falls, it will stay in the pores and cracks of the road and then restrict the bonding between the road surface and the ice. This will make the snow/ice come off easier when plowing.

Spreader De-Icing

DE-ICING

When a liquid solution is applied to an already icy/snowy road it will immediately start breaking up the ice from the top down. By mixing the right solution for your current winter temperatures, you wont be wasting salt or money.

TECHNICAL SPECIFICATIONS

Sprayer specifications and dimensions

MODEL500750/8001000160026503250
Height50"56"63"63"94"94"
Width57"69"78"78"88"88"
Length105"111"113"161"145"175"
Tank volume500 gal750/800 gal1000 gal1600 gal2650 gal3250 gal
Spray width (max)30 ft30 ft30 ft30 ft30 ft30 ft
Spray volume, 12V/24V20/40 gal/min20/40 gal/min20/40 gal/min20/40 gal/min20/40 gal/min20/40 gal/min
1 lane, Max speed @20 gal/lane mile50 mph50 mph50 mph50 mph50 mph50 mph
3 lane, Max speed @20,gal/lane mile20 mph20 mph20 mph20 mph20 mph20 mph
Weight (lbs)1150 lbs1215/1230 lbs1280 lbs1720 lbs2100 lb2500 lb
MODEL500750/8001000160026503250
Height 142 cm152 cm170 cm170 cm240 cm240 cm
Width145 cm175 cm200 cm200 cm224 cm224 cm
Length254 cm270 cm274 cm396 cm356 cm432 cm
Tank volume1893 l2839/3028 l3785 l6056 l10031 l12300 l
Spray width (max)9 m9 m9 m9 m9 m9 m
Spray volume,12V/24V 55/110 l/min55/110 l/min55/110 l/min55/110 l/min55/110 l/min55/110 l/min
1 lane, Max speed @25ml/m²85 km/h85 km/h85 km/h85 km/h85 km/h85 km/h
3 lane Max speed @25ml/m²30 km/h30 km/h30 km/h30 km/h30 km/h30 km/h
Weight (kg)520 kg550/560 kg580 kg780 kg955 kg1135 kg

OPTIONAL LIQUID SYSTEM SAVINGS CALCULATOR

See how much you can save by reducing material costs with a liquid system

Current de-icing method


Compare with


Salt consumption

lbs / year *

Salt price

$ / lb *

You can save in material costs annually

* Calculations based on the following application rates: Dry salt 30g/m2, Pre-Wet 17g/m2, Brine 35ml/m2. With a Pre-Wet system the application rate is significantly lower, as the pre-wetted salt bonds to the ground and immediately start breaking up the ice.
